DC5V Distance Measuring Sensor with Display for Cylinder Testing Machines
Draw-wire displacement encoders measure linear movements using a highly flexible steel cable.
The cable drum is attached to a sensor element which provides a proportional output signal.
Measurements are performed with high accuracy and high dynamic response. The use of high quality components guarantees a long life cycle and high operational reliability.
| Sensor Type | String Potentiometer |
|
wire rope |
0.6mm high flexible imported plastic coated wire rope |
| output signal | 0-5K, 0-10K,0-5V,0-10V,4-20mA |
| measuring range | 0-600mm |
| linear accuracy | 0.1%-0.05%FS |
| outlet tension | 4N |
| operation temperatur | -50¡ãC¡ª¡ª110¡ãC |
| vibration resistance | 10Hz-1500Hz 10G |
| cable length | 1 meter ( standard), optional |
| housing material | aluminium alloy, xidation surface treating,wear and corrosion prevention |
| power | <1W |
| operating voltage |
10-30V ( built-in) 12V,24V, 28V ( outlay) |
| repeatability accuracy | 0.01% |
| weight (kg) | 0.45 |
| life | >10 million times |
| protection class | IP54 |
| switching circuit | built-in, outlay with isolation |
JILIN SANSHENG Technology CO., LTD. Is a high-tech enterprises, focus on R&D, manufacturing and sales for industrial encoder. The company strictly implement ISO 9001:2000 quality management system and CE certification, is leading technology, most complete varieties, most cost-efficient domestic encoder manufacturers.
1.18 Month warranty:Free replacement of defective prodcuts within 18 months.
2.Questions about encoder will be answered within 24 hours.
3.OEM solution will be offered to meet all your requirement.
Q1:What's the MOQ?
A: MOQ: 1 pc
Q2:How to place the order?
A: Please contact with our sales to get the detail datasheet and confirm the part number of the encoder you need, then you can place the order online or underline.
Q3:What's the payment term?
A: We can accept T/T, Western Union and PayPal etc.
Q4:What's the lead time?
A: Standard encoder within 7 working days. Customized encoder need 15-20 working days.
